In-App Messages on iOS

In-App

In this article

In-app messages

In-app messages are handled via silent push messages from the server. When your application receives a silent push, call the Iterable iOS SDK in your app delegate, as follows:

Swift

func application(_ application: UIApplication, didReceiveRemoteNotification userInfo: [AnyHashable : Any], fetchCompletionHandler completionHandler: @escaping (UIBackgroundFetchResult) -> Void) {
    IterableAppIntegration.application(application, didReceiveRemoteNotification: userInfo, fetchCompletionHandler: completionHandler)
}

Objective-C

- (void)application:(UIApplication *)application didReceiveRemoteNotification:(NSDictionary *)userInfo fetchCompletionHandler:(void (^)(UIBackgroundFetchResult))completionHandler {
    [IterableAppIntegration application:application didReceiveRemoteNotification:userInfo fetchCompletionHandler:completionHandler];
}

Default behavior

By default, when an in-app message arrives from the server, the SDK automatically shows it if the app is in the foreground. If an in-app message is already showing when the new message arrives, the new in-app message will be shown 30 seconds after the currently displayed in-app message closes (see how to change this default value).
Once an in-app message is shown, it will be "consumed" from the server queue and removed from the local queue as well. There is no need to write any code to get this default behavior.

Overriding whether to show or skip a particular in-app message

An incoming in-app message triggers a call to the onNew method of IterableConfig.inAppDelegate (an object of type IterableInAppDelegate). To override the default behavior, set IterableConfig.inAppDelegate to a custom class that overrides the onNew method. onNew should return .show to show the incoming in-app message or .skip to skip showing it.

TIP

To determine the priority of an IterableInAppMessage object, look at its priorityLevel property. You can use this value to help determine whether or not to display it.

Swift

class YourCustomInAppDelegate: IterableInAppDelegate {
    func onNew(message: IterableInAppMessage) -> InAppShowResponse {
        // perform custom processing

        // ...

        return .show // or .skip
    }
}

let config = IterableConfig()
config.inAppDelegate = YourCustomInAppDelegate()

IterableAPI.initialize(apiKey: "<YOUR-API-KEY>", launchOptions: launchOptions, config: config)

Objective-C

@implementation YourCustomInAppDelegate : IterableInAppDelegate {
    - (enum InAppShowResponse)onNewMessage:(IterableInAppMessage * _Nonnull)message {
        // perform custom processing

        // ...

        return InAppShowResponseShow; // or InAppShowResponseSkip
    }
}

@end

IterableConfig *config = [IterableConfig new];
config.inAppDelegate = [YourCustomInAppDelegate new];

[IterableAPI initializeWithApiKey:@"<YOUR-API-KEY>" launchOptions:launchOptions config:config];

Getting the local queue of in-app messages

Until they are consumed by the app, all in-app messages that arrive from the server are stored in a local queue. To access this local queue, use the read-only IterableAPI.inAppManager property (an object which conforms to the InAppManager protocol). By default, all in-app messages in the local queue will be consumed and removed from this queue. To keep in-app messages around after they are shown, override the default behavior (as described above).

Swift

// Get the in-app messages list
let messages = IterableAPI.inAppManager.getMessages()

if messages.isEmpty {
    print("don't present when there are 0 messages")
} else {
    print("presents the first message")

    // Show an in-app message
    IterableAPI.inAppManager.show(message: messages[0])
}

// Show an in-app message without consuming, i.e., not removing it from the queue
IterableAPI.inAppManager.show(message: messages[0], consume: false)

Objective-C

// Get the in-app messages list
NSArray *messages = [IterableAPI.inAppManager getMessages];

if (messages.count == 0) {
    NSLog(@"don't present when there are 0 messages");
} else {
    NSLog(@"presents the first message");

    // Show an in-app message
    [IterableAPI.inAppManager showMessage:messages[0]];
}

// Show an in-app message without consuming, i.e., not removing it from the queue
[IterableAPI.inAppManager showMessage:messages[0] consume:NO callbackBlock:nil];

WARNING

By default, iOS apps can open HTTPS URLs, but not HTTP. Because of this, you should use HTTPS whenever possible. However, it is possible to configure your iOS apps to work with HTTP URLs by configuring App Transport Security exceptions in Xcode.

The SDK handles in-app message buttons and links as follows:

  • If the URL of the button or link uses the action:// URL scheme, the SDK passes the action to IterableConfig.customActionDelegate.handle(). If customActionDelegate (an IterableCustomActionDelegate object) has not been set, the action will not be handled.

    For the time being, the SDK will treat itbl:// URLs the same way as action:// URLs. However, this behavior will eventually be deprecated (timeline TBD), so it's best to migrate to the action:// URL scheme as it's possible to do so.

  • The iterable:// URL scheme is reserved for action names predefined by the SDK. If the URL of the button or link uses an iterable:// URL known to the SDK, it will be handled automatically and will not be passed to the custom action handler. For example, buttons or links with URL iterable://dismiss dismiss an in-app message and create in-app click and in-app close events.

  • The SDK passes all other URLs to IterableConfig.urlDelegate.handle(). If urlDelegate (an IterableUrlDelegate object) has not been set, or if it returns false for the provided URL, the URL will be opened by the system (using a web browser or other application, as applicable).

For a demonstration of how to implement and use the IterableURLDelegate and IterableCustomActionDelegate protocols, take a look at the Swift and Objective-C sample apps.

The following code demonstrates how to assign a urlDelegate and customActionDelegate to an IterableConfig object:

Swift

let config = IterableConfig()
config.urlDelegate = YourCustomUrlDelegate()
config.customActionDelegate = YourCustomActionDelegate()

Objective-C

IterableConfig *config = [IterableConfig new];
config.urlDelegate = [YourCustomUrlDelegate new];
config.customActionDelegate = [YourCustomActionDelegate new];

Changing the display interval between in-app messages

To customize the time delay between successive in-app messages (default value of 30 seconds), set inAppDisplayInterval to an appropriate value (in seconds).

Swift

let config = IterableConfig()
// 10 second delay between in-app presentations
config.inAppDisplayInterval = 10.0

Objective-C

IterableConfig *config = [IterableConfig new];
// 10 second delay between in-app presentations
config.inAppDisplayInterval = 10.0;

Pausing the display of in-app messages

In certain areas of your app, you may want to prevent interruptions. To pause the display of in-app messages, set the following property:

Swift

IterableAPI.inAppManager.isAutoDisplayPaused = true

Objective-C

IterableAPI.inAppManager.isAutoDisplayPaused = YES

With this done, the app will not automatically display new in-app messages. However, it will keep the local queue of in-app messages in sync.

TIP

While in-app message display has been paused, you can still call the show(message:) (Swift) or showMessage: (Objective-C) method on IterableAPI.inAppManager to manually display messages.

To resume the display of in-app messages from your app's queue, set isAutoDisplayPaused to false (or NO). Once you do this, the app will resume displaying any in-app messages on the queue.
